pots vibrants Sentek de 1 à 75 kN à refroidissement à air
Pots vibrants Sentek série L, de 1 à 10 kN
Pots vibrants Sentek à refroidissement à air, avec options tables horizontales et têtes d'expansion
Pot vibrant Sentek 1 kN
Performances 1 kN
Sine Force kN 0.98
Random Force kN 0.98
Shock Force (6ms) kN 1.96
Useful Frequency Range Hz 5 - 4500
Continuous Displacement mm 25
Shock Displacement mm 25
Max Velocity m/s 2
Max Acceleration Sine Peak (g) 50
Armature Diameter mm 110
Effective Armature Mass kg 2
Max Static Payload kg 70
Pot vibrant Sentek 2 kN
Performances 2 kN
Sine Force kN 1.96
Random Force kN 1.96
Shock Force (6ms) kN 3.92
Useful Frequency Range Hz 5 - 4500
Continuous Displacement mm 25
Shock Displacement mm 25
Max Velocity m/s 2
Max Acceleration Sine Peak (g) 100
Armature Diameter mm 110
Effective Armature Mass kg 2
Max Static Payload kg 70
Pot vibrant Sentek 3 kN
Performances 3 kN
Sine Force kN 2.94
Random Force kN 2.94
Shock Force (6ms) kN 5.88
Useful Frequency Range Hz 5 - 4500
Continuous Displacement mm 40
Shock Displacement mm 40
Max Velocity m/s 2
Max Acceleration Sine Peak (g) 100
Armature Diameter mm 150
Effective Armature Mass kg 3
Max Static Payload kg 120
Pot vibrant Sentek 6 kN
Performances 6 kN
Sine Force kN 5.88
Random Force kN 5.88
Shock Force (6ms) kN 11.76
Useful Frequency Range Hz 5 - 5000
Continuous Displacement mm 51
Shock Displacement mm 51
Max Velocity m/s 2
Max Acceleration (sine) (g) 100
Armature Diameter mm 200
Effective Armature Mass kg 5
Max Static Payload kg 200
Pot vibrant Sentek 10 kN
Performances 10 kN
Sine Force kN 9.8
Random Force kN 9.8
Shock Force (6ms) kN 19.6
Useful Frequency Range Hz 5 – 3400
Continuous Displacement mm 51
Shock Displacement mm 51
Max Velocity m/s 2
Max Acceleration Sine Peak (g) 100
Armature Diameter mm 2400
Effective Armature Mass kg 10
Max Static Payload kg 200
Pots vibrants Sentek série M, de 15 à 75 kN
Pots vibrants Sentek à refroidissement à air, avec options tables horizontales et têtes d'expansion
Pot vibrant Sentek 15 kN-280 mm
Performances 15 kN
Sine Force kN 14.70
Random Force kN 14.70
Shock Force (6ms) kN 29.40
Useful Frequency Range Hz 5 - 3000
Continuous Displacement mm 51
Shock Displacement mm 51
Max Velocity m/s 2
Max Acceleration (sine) (g) 80
Armature Diameter mm 280
Effective Armature Mass kg 18
Max Static Payload kg 300
Pot vibrant Sentek 22 kN-320 mm
Performances 22 kN
Sine Force kN 21.56
Random Force kN 21.56
Shock Force (6ms) kN 43.12
Useful Frequency Range Hz 5 - 3000
Continuous Displacement mm 51 ou 76
Shock Displacement mm 51 ou 76
Max Velocity m/s 2
Max Acceleration (sine) (g) 100
Armature Diameter mm 320
Effective Armature Mass kg 22
Max Static Payload kg 300
Pot vibrant Sentek 32 kN-400 mm
Performances 32 kN-400mm
Sine Force kN 31.36
Random Force kN 31.36
Shock Force (6ms) kN 62.72
Useful Frequency Range Hz 5 - 2500
Continuous Displacement mm 51 ou 76
Shock Displacement mm 51 ou 76
Max Velocity m/s 2
Max Acceleration (sine) (g) 100
Armature Diameter mm 400
Effective Armature Mass kg 32
Max Static Payload kg 500
Pot vibrant Sentek 32 kN - diam. 640 mm
Performances 32 kN-640mm
Sine Force kN 31.36
Random Force kN 31.36
Shock Force (6ms) kN 62.72
Useful Frequency Range Hz 5 - 2500
Continuous Displacement mm 51 ou 76
Shock Displacement mm 51 ou 76
Max Velocity m/s 2
Max Acceleration (sine) (g) 80
Armature Diameter mm 6400
Effective Armature Mass kg 40
Max Static Payload kg 500
Pot vibrant Sentek 40 kN
Performances 40 kN
Sine Force kN 39.20
Random Force rms kN 39.20
Shock Force (6ms) kN 78.40
Useful Frequency Range Hz 5 - 2200
Continuous Displacement mm (in) 51 ou 76
Shock Displacement mm (in) 51 ou 76
Max Velocity m/s (in/s) 2
Max Acceleration (sine) (g) 100
Armature Diameter mm 400
Effective Armature Mass kg 40
Max Static Payload kg 500
Pot vibrant Sentek 50 kN - diam. 445 mm
Performances 50 kN-445mm
Sine Force kN 49.0
Random Force rms kN 49.0
Shock Force (6ms) kN 98.0
Useful Frequency Range Hz 5 - 2500
Continuous Displacement mm (in) 51 ou 76
Shock Displacement mm (in) 51 ou 76
Max Velocity m/s (in/s) 2
Max Acceleration (sine) (g) 100
Armature Diameter mm 445
Effective Armature Mass kg 49
Max Static Payload kg 1000
Pot vibrant Sentek 50 kN - diam. 640 mm
Performances 50 kN-640mm
Sine Force kN 49.0
Random Force rms kN 49.0
Shock Force (6ms) kN 98.0
Useful Frequency Range Hz 5 - 2500
Continuous Displacement mm (in) 51 ou 76
Shock Displacement mm (in) 51 ou 76
Max Velocity m/s (in/s) 2
Max Acceleration (sine) (g) 80
Armature Diameter mm 640
Effective Armature Mass kg 63
Max Static Payload kg 1000
Pot vibrant Sentek 60 kN
Performances 60 kN
Sine Force kN 58.80
Random Force kN 58.8
Shock Force (6ms) kN 117.6
Useful Frequency Range Hz 5 - 2500
Continuous Displacement mm 51 ou 76*
Shock Displacement mm 51 ou 76*
Max Velocity m/s 2
Max Acceleration (sine) (g) 100
Armature Diameter mm 445
Effective Armature Mass kg 49
Max Static Payload kg 1000
Pot vibrant Sentek 65 kN
Performances 65 kN
Sine Force kN 63.70
Random Force kN 63.70
Shock Force (6ms) kN 127.4
Useful Frequency Range Hz 5 - 2500
Continuous Displacement mm 51 ou 76
Shock Displacement mm 51 ou 76
Max Velocity m/s 2
Max Acceleration (sine) (g) 100
Armature Diameter mm 445
Effective Armature Mass kg 60
Max Static Payload kg 1000
Pot vibrant Sentek 75 kN
Performances 75 kN
Sine Force kN 73.50
Random Force kN 73.50
Shock Force (6ms) kN 147
Useful Frequency Range Hz 5 - 2400
Continuous Displacement mm 51 ou 76
Shock Displacement mm 51 ou 76
Max Velocity m/s 2
Max Acceleration (sine) (g) 100
Armature Diameter mm 445
Effective Armature Mass kg 75
Max Static Payload kg 1000
Pots vibrants Sentek série T, de 30 à 54 kN - déplacement 4"
Pots vibrants Sentek à refroidissement à air, avec options tables horizontales et têtes d'expansion
Pot vibrant Sentek 30 kN - 4"
Performances 30 kN - 4”
Sine Force kN 29.4
Random Force kN 20.58
Shock Force (6ms) kN 58.8
Useful Frequency Range Hz 5-3000
Continuous Displacement mm 100
Shock Displacement mm 100
Max Velocity m/s 2.4
Max Acceleration (sine) (g) 80
Armature Diameter mm 320
Effective Armature Mass kg 37.5
Max Static Payload kg 500
Pot vibrant Sentek 40 kN - 4"
Performances 40kN - 4”
Sine Force kN 40
Random Force kN 39.2
Shock Force (6ms) kN 78.4
Useful Frequency Range Hz 5-2200
Continuous Displacement mm 100
Shock Displacement mm 100
Max Velocity m/s 2.4
Max Acceleration (sine) (g) 80
Armature Diameter mm 445
Effective Armature Mass kg 50
Max Static Payload kg 500
Pot vibrant Sentek 54 kN - 4"
Performances 54 kN - 4”
Sine Force kN 52.9
Random Force kN 42.32
Shock Force (6ms) kN 105.8
Useful Frequency Range Hz 5-2300
Continuous Displacement mm 100
Shock Displacement mm 100
Max Velocity m/s 2.4
Max Acceleration (sine) (g) 80
Armature Diameter mm 445
Effective Armature Mass kg 68
Max Static Payload kg 800
